| Category | Specification |
|---|---|
| Engine | |
| Model | EcoMAX TCAE-55 |
| Type | 4-cylinder, turbocharged diesel |
| Emissions | Tier 4 Final (EPA-T4F / EU Stage IIIB) |
| Displacement | 268.5 cu in (4.4 L) |
| Gross Power | 74 hp (55.2 kW) @ 2400 rpm |
| Max Torque | 295.1 lb-ft (400 Nm) @ 1200 rpm |
| Cooling System | Water-cooled |
| Starter Motor | 4.2 kW |
| Alternator | 95 amps |
| Battery | 12 V |
| Dimensions | |
| Length (w/o attachment) | 9.91 ft (3.02 m) |
| Width Over Tracks | 6.57 ft (2.00 m) |
| Height to Top of Cab | 6.89 ft (2.10 m) |
| Ground Clearance | 9.38 in (238 mm) |
| Wheelbase | 6.89 ft (2.10 m) |
| Dump Angle | 42° |
| Rollback Angle @ Ground | 30° |
| Max Rollback Angle | 94° |
| Dig Depth | 3 ft (0.91 m) below ground |
| Performance | |
| Rated Operating Capacity (retracted) | 3,695 lb (1,676 kg) |
| Rated Operating Capacity (extended) | 1,614 lb (732 kg) |
| Lift Height | 13 ft 3 in (4.03 m) |
| Forward Reach | 8 ft (2.44 m) |
| Max Discharge Height | 10.5 ft (3.2 m) |
| Travel Speed | 6.4 mph (10.3 km/h) |
| Hydraulics | |
| Standard Flow | 24 GPM (90 L/min) |
| High Flow (optional) | 33 GPM (125 L/min) |
| Main Relief Pressure | 3,335 psi (22,994 kPa) |
| Hydraulic System Capacity | 14.6 gal (55 L) |
| Capacities | |
| Fuel Tank | 27.3 gal (103 L) |
| Engine Oil | 3.7 gal (14 L) |
| Cooling System | 5.9 gal (22 L) |
| Weights | |
| Operating Weight (ROPS canopy) | 12,482.6 lb (5,662 kg) |
| Operating Weight (Cab) | 12,614.9 lb (5,722 kg) |
