| Category | Specification |
|---|---|
| Engine | |
| Model | Kubota D902 |
| Type | Liquid-cooled, 3-cylinder diesel |
| Displacement | 54.8 cu. in. (898 cc) |
| Gross Horsepower | 21.6 HP @ 3200 rpm |
| PTO Horsepower | 17.7 HP |
| Fuel Capacity | 6.6 gal (25 L) |
| Transmission & Drive | |
| Transmission Type | HST, High-Low gear shift (2 forward / reverse) |
| Drive Method | 4WD |
| Brakes | Wet disc |
| Steering | Hydrostatic Power Steering |
| Max Forward Speed | 8.4 mph (13.5 km/h) |
| Max Reverse Speed | 6.5 mph (10.5 km/h) |
| Hydraulics | |
| Total Pump Output | 6.2 gpm (23.5 l/min) |
| 3-Point Hitch | Optional |
| Lift Capacity @ 24″ | 680 lb (310 kg) |
| Dimensions | |
| Overall Length (with 3-Pt hitch) | 99 in (2515 mm) |
| Overall Width | 45.1 in (1145 mm) |
| Overall Height (ROPS) | 86.2 in (2190 mm) |
| Wheelbase | 55.1 in (1400 mm) |
| Ground Clearance | 7.6 in (193 mm) |
| Turning Radius (w/o brake) | 7.5 ft (2.3 m) |
| Weight (Open Station) | 1570 lb (712 kg) |
| Tires | |
| Front Tires | 18×8.5–10 (Turf/Industrial) |
| Rear Tires | 26×12–12 (Turf/Industrial) |
| PTO | |
| Type | Live independent PTO (with hydraulic clutch) |
| Rear PTO Speed | 540 rpm |
| Mid PTO Speed | 2500 rpm |
2023 Kubota BX23S Mini Wheel Loader KUBOTA Engine & KYB Hydraulic Cylinder Core Components
