| Category | Specification |
|---|---|
| Engine | |
| Engine Model | JCB 444 Diesel |
| Gross Power | 97.6 hp (72.8 kW) |
| Rated RPM | 2200 rpm |
| Emissions Certification | Tier IV |
| Fuel Type | Diesel |
| Performance | |
| Backhoe Stick Force | 10,690 lbs (4,847 kg) |
| Backhoe Bucket Breakout | 16,387 lbs (7,433 kg) |
| Loader Breakout Force | 14,498 lbs (6,574 kg) |
| Loader Lift Capacity | 10,225 lbs (4,638 kg) at max height |
| Digging Depth (Extended) | 21.5 ft (6.55 m) |
| Digging Depth (Retracted) | 17.6 ft (5.36 m) |
| Loader Bucket Capacity | 1.6 cu yd (1.22 m³) |
| Loader Bucket Width | 96 in (2.44 m) |
| Backhoe Bucket Capacity | 7.1 cu ft (0.20 m³) |
| Backhoe Bucket Width | 24 in (0.61 m) |
| Hydraulics | |
| Hydraulic Pump Type | Gear |
| Pump Flow | 41.0 gal/min (155.2 L/min) |
| Main Relief Pressure | 3,650 psi (251.7 bar) |
| Hydraulic System Capacity | 33.4 gal (126.4 L) |
| Hydraulic Tank Capacity | 22.0 gal (83.3 L) |
| Transmission | |
| Transmission Type | Powershift |
| Number of Speeds | 4 Forward / 4 Reverse |
| Drive | 4WD |
| Dimensions & Weights | |
| Operating Weight | 19,087 lbs (8,660 kg) |
| Overall Length | 295 in (7.49 m) |
| Overall Width | 96 in (2.44 m) |
| Height to Top of Cab | 117 in (2.97 m) |
| Ground Clearance | 11 in (0.28 m) |
| Loader Dump Height | 106 in (2.69 m) |
| Loader Dump Reach | 32 in (0.81 m) |
| Maximum Operating Height | 246 in (6.25 m) |
| Operator Environment | |
| Operator Protection | EROPS (Enclosed Roll-Over Protective Structure) |
| Steering | |
| Steering Type | Hydrostatic |
| Fuel Capacity | |
| Fuel Tank Capacity | 42.5 gal (160.8 L) |
2025 JBC 1CXT Yanmar Engine Mini Skid Steer Loader 9 Ton Rated Load Eaton Hydraulic Cylinder Crawler Loader JCB Core Components
