| Category | Specification |
|---|---|
| Engine | |
| Engine Model | Perkins 404F-E22T |
| Power | 49 hp (36.3 kW) @ 2800 rpm |
| Torque | 122 lb-ft (165 Nm) @ 1800 rpm |
| Displacement | 2.2 L |
| Emissions Standard | Tier 4 Final (No DEF or DPF required) |
| Transmission | |
| Type | Hydrostatic (Danfoss / Rexroth) |
| Max Speed | 7.5 km/h (4.6 mph) forward and reverse |
| Dimensions | |
| Operating Weight | 4262 kg (fixed dipper), 4342 kg (extending dipper) |
| Length | 3.57 m |
| Width | 1.8 m |
| Height | 2.2 m (fixed dipper), 2.27 m (extending dipper) |
| Ground Clearance | 260 mm |
| Backhoe Performance | |
| Max Dig Depth | 2.55 m (fixed dipper), 3.08 m (extending dipper) |
| Max Reach at Ground | 3.38 m (fixed), 3.91 m (extended) |
| Max Load Over Height | 2.35 m (fixed), 2.67 m (extended) |
| Bucket Rotation | 202° (fixed), 180° (extended) |
| Bucket Tearout Force | 21.6 kN (4852 lbf) |
| Dipper Tearout Force | 14.6 kN (3280 lbf) |
| Loader Performance | |
| Max Dump Height | 2.21 m |
| Load Over Height | 2.65 m |
| Loader Hinge Pin Height | 2.86 m |
| Bucket Capacity | 0.37 m³ (general purpose) |
| Breakout Force (Bucket) | 23.0 kN (5180 lbf) |
| Breakout Force (Arms) | 23.5 kN (5291 lbf) |
| Rated Operating Capacity | 665 kg (1466 lb) |
| Tipping Load | 1900 kg (4188 lb) |
| Hydraulics | |
| Pump Type | Gear pump |
| Standard Flow | 45 L/min (11.8 gpm) |
| High Flow (Optional) | 100 L/min (26.4 gpm) |
| System Pressure | 207 bar (3002 psi) manual, 220 bar (3190 psi) with EasyControls |
| Fuel & Fluids | |
| Fuel Tank Capacity | 45 L (11.8 gal) |
| Hydraulic System | 45 L (11.8 gal) |
| Engine Oil | 9.6 L (2.5 gal) |
| Cooling System | 8 L (2.1 gal) |
| Chain Cases | 10 L (2.6 gal) |
| Electrical System | |
| Voltage | 12 V |
| Battery | 72 Ah |
| Alternator | 50 A (standard), 85 A (with A/C option) |
| Operator Environment | |
| Cab Type | Fully glazed ROPS/FOPS with heater and A/C |
| Noise Level (Internal) | 82 dB(A) |
| Noise Level (External) | 101 dB(A) |
| Vibration (Whole Body) | 0.29 m/s² |
| Vibration (Hand Arm) | ≤ 2.5 m/s² (except rough tracking: 3.4 m/s²) |
