| Category | Specification |
|---|
| Production Years | 1986–1997 |
| Manufacturer | Massey Ferguson |
| Factory | Coventry, England |
| Original Price | $23,500 (1988 2WD) |
| Engine | Perkins A4.248, 4-cylinder, 4.1L diesel |
| Engine Power | 79 hp (58.9 kW) |
| PTO Power (claimed) | 69–72 hp (51.5–53.7 kW) |
| Torque | 280 Nm @ 1400 RPM |
| Fuel Tank Capacity | 28.5 gallons (107.9 liters) |
| Transmission Options | 12-speed synchromesh; 12-speed two-speed power shift |
| Chassis | 4×2 2WD |
| Steering | Power |
| Brakes | Wet disc |
| Hydraulics Type | Open center |
| Hydraulic Pressure | 3000 psi (206.8 bar) |
| Pump Flow | 4.4 gpm (linkage pump); 9.5 gpm (auxiliary pump) |
| Total Hydraulic Flow | 13.9 gpm (52.6 lpm); optional 16.8 gpm (63.6 lpm) |
| Rear Hitch Type | Category II |
| Rear Lift Capacity | 4250 lbs (1927 kg); up to 6744 lbs (3059 kg) with assist ram |
| PTO Type | Independent; 540 or 540/1000 RPM |
| Wheelbase | 84.1 inches (213 cm) |
| Length | 144.4 inches (366 cm) |
| Width | 77.7 inches (197 cm) |
| Ground Clearance | 20.9 inches (53 cm) |
| Weight | 6036 lbs (2737 kg) |
| Standard Tires | Front: 6.50-16; Rear: 16.9-24 |
| Battery | 12V; 420 CCA (2x) or 540 CCA (1x) |
| Charging System | 45-amp alternator |
